02 44 000 0009
HARTING Han 4A-STI-M-M20 Cable Gland
Datasheet
02 44 000 0009 Datasheet
Product Description
The HARTING 02 44 000 0009 is a Han 4A-STI-M-M20 cable gland, an essential component for ensuring secure and reliable cable connections within rectangular connector systems. Manufactured by HARTING, a leader in industrial connectivity, this cable gland provides robust strain relief and environmental protection, safeguarding your connections from harsh conditions. Supreme Components International is an authorised distributor of HARTING, guaranteeing the authenticity and quality of this product. This cable gland is specifically designed for use with Han 4A connectors and features an M20 thread for easy and secure installation. It is ideal for a wide range of industrial applications where reliable cable entry and protection are paramount. Trust HARTING and Supreme Components International for your connectivity needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Series | Han 4A |
| Thread Size | M20 |
| Housing Color | RAL 7032 (pebble grey) |
| Mating Cycles | Greater than or equal to 500 |
| Rated Current | 16 Amperes |
| Rated Voltage | 400 Volts |
| Cable Diameter | 4.5 millimeters to 9 millimeters |
| Clamping Range | 4.5 to 9 millimeters |
| Housing Material | Polycarbonate |
| Pollution Degree | 3 |
| Contact Resistance | Less than or equal to 3 milliOhms |
| Number Of Contacts | 4 |
| Termination Method | Screw |
| Degree Of Protection | IP44 |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
| Rated Impulse Voltage | 4 kilovolts |
| Material Flammability Class According To Ul94 | V-0 |
