HARTING Han 16 HPR EasyCon basic frame with PE connection
Datasheet
02 41 160 4201 015 Datasheet
Product Description
The HARTING 02411604201015 Han 16 HPR EasyCon basic frame with PE connection is a crucial component for establishing robust and reliable heavy-duty power connections. Manufactured by HARTING, a leader in industrial connectivity, this basic frame is designed to withstand harsh environments and demanding applications. Supreme Components International is an authorised distributor of HARTING products, ensuring you receive genuine, high-quality components. This frame provides a secure and efficient solution for power transmission, featuring a PE connection for enhanced safety. Its durable construction guarantees long-lasting performance, making it ideal for use in industrial machinery, transportation, and other demanding sectors. Trust HARTING and Supreme Components International for your critical connectivity needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Gender | Male |
| Series | Han HPR |
| Material | Aluminum die-cast |
| Wire Gauge | 0.75 to 2.5 square millimeters |
| Locking Type | Double locking lever |
| Mating Cycles | Greater than or equal to 500 |
| Nominal Current | 16 Amperes |
| Nominal Voltage | 500 Volts |
| Pollution Degree | 3 |
| Protection Degree | IP68 |
| Contact Resistance | Less than or equal to 3 milliOhms |
| Number Of Contacts | 16 |
| Termination Method | Screw |
| Insulation Resistance | Greater than 10 to the power of 10 Ohms |
