PHA11200
Solid State Relay, 12A, 24-280VAC Output, 4-15VDC Input, PCB Mount
Brand
Product Category
Magnetic Proximity Sensors
Product Sub category
Sensors for layout on PCB
PRODUCT DETAILS
Product Description
Supreme Components International, an authorised distributor, presents the Celduc Relais PHA11200, a high-performance solid state relay (SSR) designed for PCB mounting. This SSR offers a robust solution for switching AC loads with a maximum current of 12A and an output voltage range of 24-280VAC. The PHA11200 features a 4-15VDC input, making it compatible with a wide range of control signals. Its compact design and reliable performance make it suitable for applications such as lighting control, heating systems, and industrial automation. Benefit from the advantages of solid-state technology, including silent operation, fast switching speeds, and long lifespan.
Product Tags
Technical Specifications
| Approvals | Underwriters Laboratories, Verband der Elektrotechnik, Commission Europeenne |
|---|---|
| I squared t | 130 Ampere Squared Seconds |
| Load current | 12 Amperes |
| Input current | 12 Milliamperes |
| Mounting type | Printed Circuit Board Mount |
| Switching mode | Zero Voltage |
| Control voltage | 4 to 15 Volts Direct Current |
| Leakage current | 1.5 Milliamperes |
| Input voltage drop | 1.3 Volts |
| Load voltage range | 24 to 280 Volts Alternating Current |
| Dielectric strength | 4000 Volts Root Mean Square |
| Operating temperature | -30 Degrees Celsius to +80 Degrees Celsius |
